Product Details
Bolt lengths | 42.5 mm |
Bolt threads | M16 x 1.5 |
Calculated Volume (dm³) | 7.182 |
Calculated Weight (kg) | 0 |
Clamp band | 189 mm |
Clamp band position | 20° |
Cylinder length | 108 |
Distance between bolts | 120.6 mm |
GTIN | 04057877018375 |
Norm | TÜV certificate |
Port (side) | M16 x 1.5 |
Port (top) | M16 x 1.5 |
Port: working pressure [p emax.] | 10.2 |
Port angle | 0° |
Product category | Device |
ProVia warranty | 1 year |
Push-rod length | 15 mm |
Stroke | 63.5 mm |
Technical specification | AM specification |
Temperature range | -40°C to +80°C |
Type | 24 |
UPC | 193134006373 |
Weight (kg) | 3.9 |
Weight (lb) | 8.598 |
Equivalent OEMs
DennisAB4235061430
BPW
0203277800
0203277900
0544436010
0544436020
203277800
203277900
544436010
544436020
DAF
1517956
Iveco
500590336
Mercedes
0074201424
74201424
A0074201424
SAF
3454106960
Scania
1542896
1932640
Volvo
3177339
70330019
WA4235060010
Cross References
Haldex125240001
Knorr-Bremse
118867
BS3509
BS3537
II18210
